Flash Control Registers
www.ti.com
372
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
F021 Level 2 Flash Module Controller (L2FMC)
7.10.19 EEPROM Emulation Data MSW Register (FEMU_DMSW)
Figure 7-29. EEPROM Emulation Data MSW Register (FEMU_DMSW) (offset = 58h)
31 16
EMU_DMSW[63:48]
R/WP-0h
15 0
EMU_DMSW[47:32]
R/WP-0h
LEGEND: R/W = Read/Write; WP = Write in Privilege mode; -n = value after reset
Table 7-31. EEPROM Emulation Data MSW Register (FEMU_DMSW) Field Descriptions
Bit Field Description
31-0 EMU_DMSW This register can be written by the CPU in any mode.
This register is used in diagnostic mode 7 to XOR the upper 32 bits of the data being delivered to the bus
master.
7.10.20 EEPROM Emulation Data LSW Register (FEMU_DLSW)
Figure 7-30. EEPROM Emulation Data LSW Register (FEMU_DLSW) (offset = 5Ch)
31 16
EMU_DLSW[31:16]
R/WP-0h
15 0
EMU_DLSW[15:0]
R/WP-0h
LEGEND: R/W = Read/Write; WP = Write in Privilege mode; -n = value after reset
Table 7-32. EEPROM Emulation Data LSW Register (FEMU_DLSW) Field Descriptions
Bit Field Description
31-0 EMU_DLSW This register can be written by the CPU in any mode.
This register is used in diagnostic mode 7 to XOR the lower 32 bits of the data being delivered to the bus
master.
