Control Registers
www.ti.com
510
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
CPU Compare Module for Cortex-R5F (CCM-R5F)
13.3.3 CCM-R5F Status Register 2 (CCMSR2)
Figure 13-5. CCM-R5F Status Register 2 (CCMSR2) (Offset = 08h)
31 17 16
Reserved CPME2
R-0 R/W1CP-0
15 9 8 7 2 1 0
Reserved STC2 Reserved STET2 STE2
R-0 R-0 R-0 R-0 R-0
LEGEND: R/W = Read/Write; R = Read only; W1CP = Write 1 to clear in privilege mode only; -n = value after reset
Table 13-10. CCM-R5F Status Register 2 (CCMSR2) Field Descriptions
Bit Field Value Description
31-17 Reserved 0 Reads return 0. Writes have no effect.
16 CMPE2 Compare Error for VIM Output Compare Diagnostic.
Read in User and Privileged mode. Write in Privileged mode only.
0 Read: CPU signals are identical.
Write: Leaves the bit unchanged.
1 Read: CPU signal compare mismatch.
Write: Clears the bit.
15-9 Reserved Reads return 0. Writes have no effect.
8 STC2 Self-test Complete for VIM Output Compare Diagnostic.
Note: This bit is always 0 when not in self-test mode. Once set, switching from self-test mode to
other modes will clear this bit.
Read/Write in User and Privileged mode.
0 Read: Self-test on-going if self-test mode is entered.
Write: Writes have no effect.
1 Read: Self-test is complete.
Write: Writes have no effect.
7-2 Reserved Reads return 0. Writes have no effect.
1 STET2 Self-test Error Type for VIM Output Compare Diagnostic.
Read/Write in User and Privileged mode.
0 Read: Self-test failed during Compare Match Test if STE2 = 1.
Write: Writes have no effect.
1 Read: Self-test failed during Compare Mismatch Test if STE2 = 1.
Write: Writes have no effect.
0 STE2 Self-test Error for VIM Output Compare Diagnostic.
Note: This bit gets updated when the self-test is complete or an error is detected.
Read/Write in User and Privileged mode.
0 Read: Self-test passed.
Write: Writes have no effect.
1 Read: Self-test failed.
Write: Writes have no effect.
