Level 2 RAM (L2RAMW) Module
8.3.10 L2RAMW Bank to Domain Mapping Register1 (BANK_DOMAIN_MAP1)
The BANK_DOMAIN_MAP1 register, shown in Figure 8-11 and described in Table 8-12, stores the
address for which an address-parity error was detected.
Figure 8-11. L2RAMW Bank to Domain Mapping Register1 (BANK_DOMAIN_MAP1)
(offset = 48h)
31 30 28 27 26 24 23 22 20 19 18 16
Rsvd BANK15_MAP Rsvd BANK14_MAP Rsvd BANK13_MAP Rsvd BANK12_MAP
R-0 R-DS R-0 R-DS R-0 R-DS R-0 R-DS
15 14 12 11 10 8 7 6 4 3 2 0
Rsvd BANK11_MAP Rsvd BANK10_MAP Rsvd BANK9_MAP Rsvd BANK8_MAP
R-0 R-DS R-0 R-DS R-0 R-DS R-0 R-DS
LEGEND: R = Read only; DS = Device Specific; -n = value after reset
Table 8-12. L2RAMW Bank to Domain Mapping Register1 (BANK_DOMAIN_MAP1)
Field Descriptions
Bit Field Value Description
31 Reserved 0 Reads return 0. Writes have no effect.
30-28 BANK15_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 15
is associated.
27 Reserved 0 Reads return 0. Writes have no effect.
26-24 BANK14_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 14
is associated.
23 Reserved 0 Reads return 0. Writes have no effect.
22-20 BANK13_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 13
is associated.
19 Reserved 0 Reads return 0. Writes have no effect.
18-16 BANK12_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 12
is associated.
15 Reserved 0 Reads return 0. Writes have no effect.
14-12 BANK11_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 11
is associated.
11 Reserved 0 Reads return 0. Writes have no effect.
10-8 BANK10_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 10
is associated.
7 Reserved 0 Reads return 0. Writes have no effect.
6-4 BANK9_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 9 is
associated.
3 Reserved 0 Reads return 0. Writes have no effect.
2-0 BANK8_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 8 is
associated.
