I/O Multiplexing and Control Module (IOMM)
Of the three internal error events for the trip-zone inputs, nTZ4 is connected to the eQEPx error output
signal. There are two eQEP modules on this microcontroller, and registers in the I/O multiplexing module
are used to allow a flexible scheme for the connection between the eQEPx error signal and the nTZ4
inputs of the ePWMx modules.
Table 6-7. Controls for eQEPx_ERROR Connection to ePWMx nTZ4 Inputs
ePWMx Module
Control for nTZ4 =
not(eQEP1ERR or eQEP2ERR)
(default connection)
Control for nTZ4 =
not(eQEP1ERR)
Control for nTZ4 =
not(eQEP2ERR)
ePWM1 PINMMR167[0] = 1
PINMMR167[0] = 0
PINMMR167[1] = 1
PINMMR167[1:0] = "00"
PINMMR167[2] = 1
ePWM2 PINMMR167[8] = 1
PINMMR167[8] = 0
PINMMR167[9] = 1
PINMMR167[9:8] = "00"
PINMMR167[10] = 1
ePWM3 PINMMR167[16] = 1
PINMMR167[16] = 0
PINMMR167[17] = 1
PINMMR167[17:16] = "00"
PINMMR167[18] = 1
ePWM4 PINMMR167[24] = 1
PINMMR167[24] = 0
PINMMR167[25] = 1
PINMMR167[25:24] = "00"
PINMMR167[26] = 1
ePWM5 PINMMR168[0] = 1
PINMMR168[0] = 0
PINMMR168[1] = 1
PINMMR168[1:0] = "00"
PINMMR168[2] = 1
ePWM6 PINMMR168[8] = 1
PINMMR168[8] = 0
PINMMR168[9] = 1
PINMMR168[9:8] = "00"
PINMMR168[10] = 1
ePWM7 PINMMR168[16] = 1
PINMMR168[16] = 0
PINMMR168[17] = 1
PINMMR168[17:16] = "00"
PINMMR168[18] = 1
6.5.10 Control for Input Connections to eCAPx Modules
Each eCAPx module has a single input from the device terminals. This input can be connected to the
eCAPx module in one of two ways:
1. Double-synchronized using VCLK3
2. Double-synchronized using VCLK3 and then filtered through a 6-VCLK3-cycle counter
Registers in the I/O multiplexing module are used to control these input connections for each eCAPx
module.
Table 6-8. Controls for eCAPx Inputs
eCAPx Input
Control for Double-VCLK3-
Synchronized Input
(default connection)
Control for Double-VCLK3-
Synchronized and
6-VCLK3-Filtered Input
eCAP1 PINMMR169[0] = 0
PINMMR169[0] = 0
PINMMR169[1] = 1
eCAP2 PINMMR169[8] = 0
PINMMR169[8] = 0
PINMMR169[9] = 1
eCAP3 PINMMR169[16] = 0
PINMMR169[16] = 0
PINMMR169[17] = 1
eCAP4 PINMMR169[24] = 0
PINMMR169[24] = 0
PINMMR169[25] = 1
eCAP5 PINMMR170[0] = 0
PINMMR170[0] = 0
PINMMR170[1] = 1
eCAP6 PINMMR170[8] = 0
PINMMR170[8] = 0
PINMMR170[9] = 1
