FlexRay Module
26.2.16 Assignment of FlexRay Configuration Parameters
The following table shows the assignment of the FlexRay parameters as defined in the FlexRay Protocol
Specification and the corresponding bit fields of the FlexRay module.
Table 26-17. Assignment of FlexRay Configuration Parameters
Parameter Bit(field)
pKeySlotusedForStartup SUCC1.TXST
pKeySlotUsedForSync SUCC1.TXSY
gColdStartAttempts SUCC1.CSA(4-0)
pAllowPassiveToActive SUCC1.PTA(4-0)
pWakeupChannel SUCC1.WUCS
pSingleSlotEnabled SUCC1.TSM
pAllowHaltDueToClock SUCC1.HCSE
pChannels SUCC1.CCHASUCC1.CCHB
pdListenTimeOut SUCC2.LT(20-0)
gListenNoise SUCC2.LTN(3-0)
gMaxWithoutClockCorrectionPassive SUCC3.WCP(3-0)
gMaxWithoutClockCorrectionFatal SUCC3.WCF(3-0)
gNetworkManagementVectorLength NEMC.NML(3-0)
gdTSSTransmitter PRTC1.TSST(3-0)
gdCASRxLowMax PRTC1.CASM(6-0)
gdSampleClockPeriod PRTC1.BRP(1-0)
pSamplesPerMicrotick PRTC1.BRP(1-0)
gdWakeupSymbolRxWindow PRTC1.RXW(8-0)
pWakeupPattern PRTC1.RWP(5-0)
gdWakeupSymbolRxIdle PRTC2.RXI(5-0)
gdWakeupSymbolRxLow PRTC2.RXL(5-0)
gdWakeupSymbolTxIdle PRTC2.TXI(7-0)
gdWakeupSymbolTxLow PRTC2.TXL(5-0)
gPayloadLengthStatic MHDC.SFDL(6-0)
pLatestTx MHDC.SLT(12-0)
pMicroPerCycle GTUC1.UT(19-0)
gMacroPerCycle GTUC2.MPC(13-0)
gSyncNodeMax GTUC2.SNM(3-0)
pMicroInitialOffset[A] GTUC3.UIOA(7-0)
pMicroInitialOffset[B] GTUC3.UIOB(7-0)
pMacroInitialOffset[A] GTUC3.MIOA(6-0)
pMacroInitialOffset[B] GTUC3.MIOB(6-0)
gdNIT GTUC4.NIT(13-0)
gOffsetCorrectionStart GTUC4.OCS(13-0)
pDelayCompensation[A] GTUC5.DCA(7-0)
pDelayCompensation[B] GTUC5.DCB(7-0)
pClusterDriftDamping GTUC5.CDD(4-0)
pDecodingCorrection GTUC5.DEC(7-0)
pdAcceptedStartupRange GTUC6.ASR(10-0)
pdMaxDrift GTUC6.MOD(10-0)
gdStaticSlot GTUC7.SSL(9-0)
gNumberOfStaticSlots GTUC7.NSS(9-0)
gdMinislot GTUC8.MSL(5-0)
