www.ti.com
HWAG Registers
1057
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer (N2HET) Module
23.5.16 HWAG Teeth Number Register (HWATHNB)
Figure 23-104. HWAG Teeth Number Register (HWATHNB)
31 16
Reserved
R-0
15 8 7 0
Reserved THNB
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 23-68. HWAG Teeth Number Register (HWATHNB) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reads return 0. Writes have no effect.
7-0 THNB 0-FFh Teeth Number. Sets the teeth number with the maximum value of the toothed wheel. This
must be equal to N-1 real teeth (that is, 57 for a 60-2 toothed wheel).
23.5.17 HWAG Current Teeth Number Register (HWATHVL)
Figure 23-105. HWAG Current Teeth Number Register (HWATHVL)
31 16
Reserved
R-0
15 8 7 0
Reserved THVL
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 23-69. HWAG Current Teeth Number Register (HWATHVL) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reads return 0. Writes have no effect.
7-0 THVL 0-FFh Teeth Value. Provides the current teeth number.
