System Memory Protection Unit (NMPU)
11.4.9 MPU Type Register (MPUTYPE)
Figure 11-12. MPU Type Register (MPUTYPE) [offset = 2Ch]
31 16
Reserved
R-0
15 8 7 0
NUMREG Reserved
R-x R-0
LEGEND: R = Read only; -n = value after reset; -x = value is implementation defined
Table 11-12. MPU Type Register (MPUTYPE) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reserved. Reads return 0.
15-8 NUMREG Number of MPU Regions. Indicates the number of implemented MPU regions.
0 Reserved
1h 1 MPU region is implemented.
2h 2 MPU regions are implemented.
3h 3 MPU regions are implemented.
4h 4 MPU regions are implemented.
5h 5 MPU regions are implemented.
6h 6 MPU regions are implemented.
7h 7 MPU regions are implemented.
8h 8 MPU regions are implemented.
All other values Reserved
7-0 Reserved 0 Reserved. Reads return 0.
