www.ti.com
POM Control Registers
385
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
F021 Level 2 Flash Module Controller (L2FMC)
7.11.4 POM Region Start Address Register (POMPROGSTARTx)
This set of registers contains the start address of each region which is to be remapped. These registers
are at an offset 200h + (10h x region number). Region numbers are counted from 0 onwards.
Figure 7-49. POM Region Start Address Register (POMPROGSTARTx) (offset = 200h, 210h,..)
31 23 22 16
Reserved STARTADDRESS
R-0 R/WP-0
15 6 5 0
STARTADDRESS Reserved
R/WP-0 R-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in Privilege Mode; -n = value after reset
Table 7-52. POM Region Start Address Register (POMPROGSTARTx)
Field Descriptions
Bit Field Value Description
31-23 Reserved 0 Reads return 0. Writes have no effect.
22-6 STARTADDRESS Start address of the program memory region.
5-0 Reserved 0 Reads return 0. Writes have no effect.
7.11.5 POM Overlay Region Start Address Register (POMOVLSTARTx)
Contains the start address of the overlay region in volatile memory.
Figure 7-50. POM Overlay Region Start Address Register (POMOVLSTARTx) (offset = 204h, 214h,...)
31 23 22 16
Reserved STARTADDRESS
R-0 R/WP-0
15 6 5 0
STARTADDRESS Reserved
R/WP-0 R-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in Privilege Mode; -n = value after reset
Table 7-53. POM Overlay Region Start Address Register (POMOVLSTARTx)
Field Descriptions
Bit Field Value Description
31-23 Reserved 0 Reads return 0. Writes have no effect.
22-6 STARTADDRESS Start address of the program memory region.
5-0 Reserved 0 Reads return 0. Writes have no effect.
