PBIST Control Registers
425
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Programmable Built-In Self-Test (PBIST) Module
9.5.13 RAM Info Mask Upper Register (RINFOU)
This register is used to select the RAM groups 33 to 64 to run the algorithms selected in the ALGO
register. For an algorithm to be executed on a particular RAM group, the corresponding bit in this register
should be set to 1. The default value of this register is all 1s, which means all the RAM Info Groups would
be selected. Figure 9-18 and Table 9-17 illustrate this register.
Figure 9-18. RAM Info Mask Upper Register (RINFOU) [offset = 01CCh]
31 24 23 16
RINFOU3 RINFOU2
R/W-FFh R/W-FFh
15 8 7 0
RINFOU1 RINFOU0
R/W-FFh R/W-FFh
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 9-17. RAM Info Mask Upper Register (RINFOU) Field Descriptions
Bit Field Value Description
31 0 RAM Group 64 is not selected.
1 Selects group 64 for PBIST run.
30 0 RAM Group 63 is not selected.
1 Selects RAM group 63 for PBIST run.
: :
0 0 RAM Group 33 is not selected.
1 Selects RAM Group 33 for PBIST run.
31-0 0 None of RAM Groups 33 to 64 are selected.
To Next Page
