Architecture
2.4.5 Embedded Trace Macrocell (ETM-R5)
The TMS570LC43x microcontrollers contain an ETM-R5 module with a 32-bit internal data port. The ETM-
R5 module is connected to a Trace Port Interface Unit (TPIU) with a 32-bit data bus; the TPIU provides a
35-bit (32-bit data and 3-bit control) external interface for trace. The ETM-R5 is CoreSight compliant and
follows the ETM v3 specification. For more details on the ETM-R5 specification, refer to the Embedded
Trace Macrocell Architecture Specification.
The ETM clock source is selected as either VCLK or the external ETMTRACECLKIN pin. The selection is
done by the EXTCTLOUT control bits of the TPIU EXTCTL_Out_Port register. The address of this register
is TPIU base address + 0x404.
Before you begin accessing TPIU registers, the TPIU should be unlocked via the CoreSight key and 1h or
2h should be written to this register.
Figure 2-6. EXTCTL_Out_Port Register [offset = 404h]
31 16
Reserved
R-0
15 2 1 0
Reserved EXTCTLOUT
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 2-13. EXTCTL_Out_Port Register Field Descriptions
Bit Field Value Description
31-2 Reserved 0 Reads return 0. Writes have no effect.
1-0 EXTCTLOUT EXTCTL output control.
0 Tied-zero
1h VCLK
2h ETMTRACECLKIN
3h Tied-zero
2.4.6 Safety Considerations for Clocks
The TMS570LC43x microcontrollers are targeted for use in several safety-critical applications. The
following sections describe the internal or external monitoring mechanisms that detect and signal clock
source failures.
