STC Module Assignments

www.ti.com

436

SPNU563A–March 2018

Submit Documentation Feedback

Self-Test Controller (STC) Module

10.2 STC Module Assignments

There are two instances of STC modules available on this device, see Table 10-1. STC1 is used for

running self-test on the redundant CPUs and µSCU. STC2 is used for running self-test on the two nHET

modules. The two instances are independent of each other.

Table 10-1. STC Module Assignments

Module Segments Targeted IP

Number of

Intervals

STCCLK Derived

From Note

STC1 Segment 0 CPU1 and CPU2 125 GCLK1 Segment 0 allows CPU1 and

CPU2 to be tested in parallel

or individually.

Segment 1 µSCU (ACP Block) 3 GCLK1 None

STC2 Segment 0 nHET1 and nHET2 57 VCLK2 Segment 0 allows nHET1 and

nHET2 to be tested in parallel

or individually.

Default Chapter2
