Page #948 background imageLoading...
Page #948 background image
ADC Registers
www.ti.com
948
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Analog To Digital Converter (ADC) Module
22.3.69 ADC Event Group Channel Selection Mode Control Register
(ADEVCHNSELMODECTRL)
Figure 22-100 and Table 22-75 describe the ADEVCHNSELMODECTRL register.
Figure 22-100. ADC Event Group Channel Selection Mode Control Register
(ADEVCHNSELMODECTRL) (offset = 190h)
31 4 3 0
Reserved EV_ENH_CHNSEL_MODE_ENABLE
R-0 R/W-5h
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 22-75. ADC Event Group Channel Selection Mode Control Register
(ADEVCHNSELMODECTRL) Field Descriptions
Bit Field Value Description
31-4 Reserved 0 Reads return 0. Writes have no effect.
3-0 EV_ENH_CHNSEL_
MODE_ENABLE
Enable enhanced channel selection mode for Event group. Refer to Section 22.2.2.2.2 for
a description of the enhanced channel selection mode.
5h Read: Indicates that the enhanced channel selection mode for Event group is not enabled.
The default sequential channel selection mode is used for Event group conversions.
Write: Disables the enhanced channel selection mode for Event group and enables the
sequential channel selection mode.
Ah Read: Indicates that the enhanced channel selection mode for Event group is enabled.
Write: Enables the enhanced channel selection mode for Event group.
All other values Writing any value other than 5h or Ah to this field has no effect on the selected channel
selection mode for the Event group, and the ADC module continues to use the channel
selection mode that was previously programmed channel selection mode.
22.3.70 ADC Group1 Channel Selection Mode Control Register (ADG1CHNSELMODECTRL)
Figure 22-101 and Table 22-76 describe the ADG1CHNSELMODECTRL register.
Figure 22-101. ADC Group1 Channel Selection Mode Control Register
(ADG1CHNSELMODECTRL) (offset = 194h)
31 4 3 0
Reserved G1_ENH_CHNSEL_MODE_ENABLE
R-0 R/W-5h
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 22-76. ADC Group1 Channel Selection Mode Control Register
(ADG1CHNSELMODECTRL) Field Descriptions
Bit Field Value Description
31-4 Reserved 0 Reads return 0. Writes have no effect.
3-0 G1_ENH_CHNSEL_
MODE_ENABLE
Enable enhanced channel selection mode for Group1. Refer to Section 22.2.2.2.2 for a
description of the enhanced channel selection mode.
5h Read: Indicates that the enhanced channel selection mode for Group1 is not enabled. The
default sequential channel selection mode is used for Group1 conversions.
Write: Disables the enhanced channel selection mode for Group1 and enables the
sequential channel selection mode.
Ah Read: Indicates that the enhanced channel selection mode for Group1 is enabled.
Write: Enables the enhanced channel selection mode for Group1.
All other values Writing any value other than 5h or Ah to this field has no effect on the selected channel
selection mode for the Group1, and the ADC module continues to use the channel
selection mode that was previously programmed channel selection mode.
