I/O Multiplexing and Control Module (IOMM)
6.5 Control of Special Multiplexed Options
Several of the PINMMR registers are used to control specific functions on this microcontroller.
Table 6-3. Special Multiplexed Controls
Control Function
PINMMR
Register
Address
Offset
PINMMR Register Bits Used Reference
GIOB[2] Select 390h PINMMR160[16] PINMMR160[17] See Section 6.5.6
MII/RMII Select PINMMR160[24] See Section 6.5.3
ADC Alternate Trigger Table Select 394h PINMMR161[0] PINMMR161[1] See Section 6.5.4
ADC1 Alternate Trigger Source for
Trigger Input 2
PINMMR161[8] PINMMR161[9]
ADC1 Alternate Trigger Source for
Trigger Input 4
PINMMR161[16] PINMMR161[17]
ADC1 Alternate Trigger Source for
Trigger Input 6
PINMMR161[24] PINMMR161[25]
ADC1 Alternate Trigger Source for
Trigger Input 7
398h PINMMR162[0] PINMMR162[1]
ADC1 Alternate Trigger Source for
Trigger Input 8
PINMMR162[8] PINMMR162[9]
ADC2 Alternate Trigger Source for
Trigger Input 2
PINMMR162[16] PINMMR162[17]
ADC2 Alternate Trigger Source for
Trigger Input 4
PINMMR162[24] PINMMR162[25]
ADC2 Alternate Trigger Source for
Trigger Input 6
39Ch PINMMR163[0] PINMMR163[1]
ADC2 Alternate Trigger Source for
Trigger Input 7
PINMMR163[8] PINMMR163[9]
ADC2 Alternate Trigger Source for
Trigger Input 8
PINMMR163[16] PINMMR163[17]
Selecting Start of Conversion
(SOC1A) of ePWM1
3A0h PINMMR164[0] See Section 6.5.5
Selecting Start of Conversion
(SOC2A) of ePWM2
PINMMR164[8]
Selecting Start of Conversion
(SOC3A) of ePWM3
PINMMR164[16]
Selecting Start of Conversion
(SOC4A) of ePWM4
PINMMR164[24]
Selecting Start of Conversion
(SOC5A) of ePWM5
3A4h PINMMR165[0]
Selecting Start of Conversion
(SOC6A) of ePWM6
PINMMR165[8]
Selecting Start of Conversion
(SOC7A) of ePWM7
PINMMR165[16]
ePWM1 SYNCI Select PINMMR165[24] PINMMR165[25] See Section 6.5.8
ePWMx TBCLKSYNC Enable 3A8h PINMMR166[1] See Section 6.5.7
ePWM1 Trip Zone 4 Select 3ACh PINMMR167[0] PINMMR167[1] PINMMR167[2] See Section 6.5.9
ePWM2 Trip Zone 4 Select PINMMR167[8] PINMMR167[9] PINMMR167[10]
ePWM3 Trip Zone 4 Select PINMMR167[16] PINMMR167[17] PINMMR167[18]
ePWM4 Trip Zone 4 Select PINMMR167[24] PINMMR167[25] PINMMR167[26]
ePWM5 Trip Zone 4 Select 3B0h PINMMR168[0] PINMMR168[1] PINMMR168[2]
ePWM6 Trip Zone 4 Select PINMMR168[8] PINMMR168[9] PINMMR168[10]
ePWM7 Trip Zone 4 Select PINMMR168[16] PINMMR168[17] PINMMR168[18]
