I/O Multiplexing and Control Module (IOMM)
Table 6-3. Special Multiplexed Controls (continued)
Control Function
PINMMR
Register
Address
Offset
PINMMR Register Bits Used Reference
eCAP1 Input Filtering Select 3B4h PINMMR169[0] PINMMR169[1] See Section 6.5.10
eCAP2 Input Filtering Select PINMMR169[8] PINMMR169[9]
eCAP3 Input Filtering Select PINMMR169[16] PINMMR169[17]
eCAP4 Input Filtering Select PINMMR169[24] PINMMR169[25]
eCAP5 Input Filtering Select 3B8h PINMMR170[0] PINMMR170[1]
eCAP6 Input Filtering Select PINMMR170[8] PINMMR170[9]
eQEP1A Input Filtering Select PINMMR170[16] PINMMR170[17] See Section 6.5.11
eQEP1B Input Filtering Select PINMMR170[24] PINMMR170[25]
eQEP1I Input Filtering Select 3BCh PINMMR171[0] PINMMR171[1]
eQEP1S Input Filtering Select PINMMR171[8] PINMMR171[9]
eQEP2A Input Filtering Select PINMMR171[16] PINMMR171[17]
eQEP2B Input Filtering Select PINMMR171[24] PINMMR171[25]
eQEP2I Input Filtering Select 3C0h PINMMR172[0] PINMMR172[1]
eQEP2S Input Filtering Select PINMMR172[8] PINMMR172[9]
ePWMx Trip Zone1 (TZ1n) Input
Filtering Select
PINMMR172[16] PINMMR172[17] PINMMR172[18] See Section 6.5.9
ePWMx Trip Zone2 (TZ2n) Input
Filtering Select
PINMMR172[24] PINMMR172[25] PINMMR172[26]
ePWMx Trip Zone3 (TZ3n) Input
Filtering Select
3C4h PINMMR173[0] PINMMR173[1] PINMMR173[2]
ePWM SYNCI Input Filtering Select PINMMR173[8] PINMMR173[9] PINMMR173[10]
Temperature Sensor 1 Select PINMMR173[16] PINMMR173[17] See Section 6.5.13
Temperature Sensor 2 Select PINMMR173[24] PINMMR173[25]
Temperature Sensor 3 Select 3C8h PINMMR174[0] PINMMR174[1]
EMIF Output Enable PINMMR174[8] PINMMR174[9] See Section 6.5.2
ESM1 nERROR Select PINMMR174[16] PINMMR174[17] See Section 6.5.11.1
Temperature Sensor Power Down
Enable
PINMMR174[24] See Section 6.5.13
GIOA[0] DMA Request Select 3CCh PINMMR175[0] See Section 6.5.12
GIOA[1] DMA Request Select PINMMR175[8]
GIOA[2] DMA Request Select PINMMR175[16]
GIOA[3] DMA Request Select PINMMR175[24]
GIOA[4] DMA Request Select 3D0h PINMMR176[0]
GIOA[5] DMA Request Select PINMMR176[8]
GIOA[6] DMA Request Select PINMMR176[16]
GIOA[7] DMA Request Select PINMMR176[24]
GIOB[0] DMA Request Select 3D4h PINMMR177[0]
GIOB[1] DMA Request Select PINMMR177[8]
GIOB[2] DMA Request Select PINMMR177[16]
GIOB3] DMA Request Select PINMMR177[24]
GIOB[4] DMA Request Select 3D8h PINMMR178[0]
GIOB[5] DMA Request Select PINMMR178[8]
GIOB[6] DMA Request Select PINMMR178[16]
GIOB[7] DMA Request Select PINMMR178[24]
NHET2 Pin Disable Select 3DCh PINMMR179[0] PINMMR179[1] See Section 6.5.6
NHET1 Pin Disable Select PINMMR179[8] PINMMR179[9]
