PLL Control Registers
537
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Oscillator and PLL
14.6.3 SSW PLL BIST Control Register 3 (SSWPLL3)
This is observation register used to log counter value for CLKOUT counter inside PLL wrapper. The
SSWPLL3 register is shown in Figure 14-8 and described in Table 14-8. This register applies to PLL1, but
does not apply to PLL2.
Figure 14-8. SSW PLL BIST Control Register 3 (SSWPLL3) [offset = 2Ch]
31 16
SSW_CLKOUT_COUNT
R-0
15 0
SSW_CLKOUT_COUNT
R-0
LEGEND: R = Read only; -n = value after reset
Table 14-8. SSW PLL BIST Control Register 3 (SSWPLL3) Field Descriptions
Bit Field Description
31-0 SSW_CAPTURE_COUNT Value of CLKout count register. This counter increments based upon the PLL output (prior
to the R-divider).
