Texas Instruments TMS570LC4357 User Manual

Flash Control Registers www.ti.com
366
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
F021 Level 2 Flash Module Controller (L2FMC)
7.10.14 Flash Bank Power Mode Register (FBPWRMODE)
Figure 7-24. Flash Bank Power Mode Register (FBPWRMODE) (offset = 40h)
31 16
Reserved
R-505h
15 14 13 4 3 2 1 0
BANKPWR7 Reserved BANKPWR1 BANKPWR0
R/WP-3h R-3FFh R/WP-3h R/WP-3h
LEGEND: R/W = Read/Write; R = Read only; WP = Write in Privilege Mode; -n = value after reset
Table 7-26. Flash Bank Power Mode Register (FBPWRMODE) Field Descriptions
Bit Field Value Description
31-16 Reserved 505h Do not write to these register bits.
15-14 BANKPWR7 Bank 7 Power Mode.
0 Bank sleep mode
1h Bank standby mode
2h Reserved
3h Bank active mode
13-4 Reserved 3FFh Do not write to these register bits.
3-2 BANKPWR1 Bank 1 Power Mode.
0 Bank sleep mode
1h Bank standby mode
2h Reserved
3h Bank active mode
1-0 BANKPWR0 Bank 0 Power Mode.
0 Bank sleep mode
1h Bank standby mode
2h Reserved
3h Bank active mode
