www.ti.com
ADC Registers
941
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Analog To Digital Converter (ADC) Module
22.3.56 ADC Magnitude Compare Interrupt Enable Set Register (ADMAGINTENASET)
ADC Magnitude Compare Interrupt Enable Set Register (ADMAGINTENASET) is shown in Figure 22-87
and described in Table 22-62.
Figure 22-87. ADC Magnitude Compare Interrupt Enable Set Register (ADMAGINTENASET)
[offset = 158h]
31 3 2 0
Reserved MAG_INT_ENA_SET
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 22-62. ADC Magnitude Compare Interrupt Enable Set Register (ADMAGINTENASET)
Field Descriptions
Bit Field Value Description
31-3 Reserved 0 Reads return 0. Writes have no effect.
2-0 MAG_INT_ENA_SET Each of these three bits, when set, enable the corresponding magnitude compare interrupt.
Any operation mode read/write for each bit:
0 The enable status of the corresponding magnitude compare interrupt is left unchanged.
1 The corresponding magnitude compare interrupt is enabled.
22.3.57 ADC Magnitude Compare Interrupt Enable Clear Register (ADMAGINTENACLR)
ADC Magnitude Compare Interrupt Enable Clear Register (ADMAGINTENACLR) is shown in Figure 22-88
and described in Table 22-63.
Figure 22-88. ADC Magnitude Compare Interrupt Enable Clear Register (ADMAGINTENACLR)
[offset = 15Ch]
31 3 2 0
Reserved MAG_INT_ENA_CLR
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 22-63. ADC Magnitude Compare Interrupt Enable Clear Register (ADMAGINTENACLR)
Field Descriptions
Bit Field Value Description
31-3 Reserved 0 Reads return 0. Writes have no effect.
2-0 MAG_INT_ENA_CLR Each of these three bits, when set, enable the corresponding magnitude compare interrupt.
Any operation mode read/write for each bit:
0 The enable status of the corresponding magnitude compare interrupt is left unchanged.
1 The corresponding magnitude compare interrupt is disabled.
