Architecture
2.2.2 Memory-Map Table
The control and status registers for each module are mapped within the CPU’s 4GB memory space. Some
modules also have associated memories, which are also mapped within this space.
Table 2-2 shows the starting and ending addresses of each module’s register frame and any associated
memory. The table also shows the response generated by the module or the interconnect whenever an
access is made to an unimplemented location inside the register or memory frame.
Table 2-2. Module Registers / Memories Memory-Map
Target Name
Memory
Select
Address Range
Frame Size Actual Size
Response for
Access to
Unimplemented
Locations in
FrameStart End
Level 2 Memories
Level 2 Flash Data
Space
0x0000_0000 0x003F_FFFF 4MB 4MB Abort
Level 2 SRAM 0x0800_0000 0x083F_FFFF 4MB 512kB Abort
Level 2 SRAM ECC 0x0840_0000 0x087F_FFFF 4MB 512kB
Accelerator Coherency Port
Accelerator
Coherency Port
0x0800_0000 0x087F_FFFF 8MB 512kB Abort
Level 1 Cache Memories
Cortex-R5F Data
Cache Memory
0x3000_0000 0x30FF_FFFF 16MB 32kB Abort
Cortex-R5F
Instruction Cache
Memory
0x3100_0000 0x31FF_FFFF 16MB 32kB
External Memory Accesses
EMIF Chip Select 2
(asynchronous)
0x6000_0000 0x63FF_FFFF 64MB 16MB Access to
Reserved space
EMIF Chip Select 3
(asynchronous)
0x6400_0000 0x67FF_FFFF 64MB 16MB Generates Abort
EMIF Chip Select 4
(asynchronous)
0x6800_0000 0x6BFF_FFFF 64MB 16MB
EMIF Chip Select 0
(synchronous)
0x8000_0000 0x87FF_FFFF 128MB 128MB
Flash OTP, ECC, EEPROM Bank
Customer OTP,
Bank0
0xF000_0000 0xF000_1FFF 8kB 4kB Abort
Customer OTP,
Bank1
0xF000_2000 0xF000_3FFF 8kB 4kB Abort
Customer OTP,
EEPROM Bank
0xF000_E000 0xF000_FFFF 8kB 1kB Abort
Customer OTP-ECC,
Bank0
0xF004_0000 0xF004_03FF 1kB 512B Abort
Customer OTP-ECC,
Bank1
0xF004_0400 0xF004_07FF 1kB 512B Abort
Customer OTP-ECC,
EEPROM Bank
0xF004_1C00 0xF004_1FFF 1kB 128B Abort
TI OTP, Bank0 0xF008_0000 0xF008_1FFF 8kB 4kB Abort
TI OTP, Bank1 0xF008_2000 0xF008_3FFF 8kB 4kB Abort
TI OTP, EEPROM
Bank
0xF008_E000 0xF008_FFFF 8kB 1kB Abort
TI OTP-ECC, Bank0 0xF00C_0000 0xF00C_03FF 1kB 512B Abort
TI OTP-ECC, Bank1 0xF00C_0400 0xF00C_07FF 1kB 512B Abort
