High-End Timer (N2HET) Module
23.4.23 N2HET Open Drain Register (HETPDR)
Values in this register enable or disable the open drain capability of the data pins.
N2HET1: offset = FFF7 B860h; N2HET2: offset = FFF7 B960h
Figure 23-78. N2HET Open Drain Register (HETPDR)
31 16
HETPDR
R/W-0
15 0
HETPDR
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 23-39. N2HET Open Drain Register (HETPDR) Field Descriptions
Bit Field Value Description
31-0 HETPDR[n] Open drain control for HET[n] pins
0 The pin is configured in push/pull mode.
1 The pin is configured in open drain mode. The HETDOUT register controls the state of the output
buffer:
HETDOUT[n] = 0 The output buffer of pin HET[n] is driven low.
HETDOUT[n] = 1 The output buffer of pin HET[n] is tristated.
23.4.24 N2HET Pull Disable Register (HETPULDIS)
Values in this register enable or disable the pull-up/-down functionality of the pins.
N2HET1: offset = FFF7 B864h; N2HET2: offset = FFF7 B964h
Figure 23-79. N2HET Pull Disable Register (HETPULDIS)
31 16
HETPULDIS
R/W-n
15 0
HETPULDIS
R/W-n
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset; n is device dependent, see device specific data sheet
Table 23-40. N2HET Pull Disable Register (HETPULDIS) Field Descriptions
Bit Field Value Description
31-0 HETPULDIS[n] Pull disable for N2HET pins
0 The pull functionality is enabled on pin HET[n].
1 The pull functionality is disabled on pin HET[n].
NOTE: See device data sheet for which pins provide programmable pullups/pulldowns.
Table 23-9 shows how the register bits of HETDIR, HETPULDIS, and HETPSL are affecting
the N2HET pins.
