Programmable Built-In Self-Test (PBIST) Module
9.5 PBIST Control Registers
PBIST controller uses configuration registers for programming the algorithm and its execution. All the
configuration registers are memory mapped for access by the CPU through the Peripheral Bus interface.
The base address for the control registers is FFFF E400h.
NOTE: There is no watchdog functionality implemented in the PBIST controller. If a bad code is
executed, the PBIST runs forever. The PBIST controller does not guard against this
situation.
Registers are accessible only when the clock to the PBIST controller is active. The clock is
activated by first writing 1h to the PACT register.
Table 9-1. PBIST Registers
Offset Acronym Register Description Section
160h RAMT RAM Configuration Register Section 9.5.1
164h DLR Datalogger Register Section 9.5.2
180h PACT PBIST Activate/Clock Enable Register Section 9.5.3
184h PBISTID PBIST ID Register Section 9.5.4
188h OVER Override Register Section 9.5.5
190h FSRF0 Fail Status Fail Register 0 Section 9.5.6
198h FSRC0 Fail Status Count Register 0 Section 9.5.7
19Ch FSRC1 Fail Status Count Register 1 Section 9.5.7
1A0h FSRA0 Fail Status Address Register 0 Section 9.5.8
1A4h FSRA1 Fail Status Address Register 1 Section 9.5.8
1A8h FSRDL0 Fail Status Data Register 0 Section 9.5.9
1B0h FSRDL1 Fail Status Data Register 1 Section 9.5.9
1C0h ROM ROM Mask Register Section 9.5.10
1C4h ALGO ROM Algorithm Mask Register Section 9.5.11
1C8h RINFOL RAM Info Mask Lower Register Section 9.5.12
1CCh RINFOU RAM Info Mask Upper Register Section 9.5.13
