N2HET Control Registers

1043

SPNU563A–March 2018

Submit Documentation Feedback

High-End Timer (N2HET) Module

23.4.33 N2HET Pin Disable Register (HETPINDIS)

N2HET1: offset = FFF7 B894h; N2HET2: offset = FFF7 B994h

Figure 23-88. N2HET Pin Disable Register (HETPINDIS)

31 16

HETPINDIS

R/W-0

15 0

HETPINDIS

R/W-0

LEGEND: R/W = Read/Write; R = Read only; -n = value after reset

Table 23-50. NHET Pin Disable Register (HETPINDIS) Field Descriptions

Bit Field Value Description

31-0 HETPINDIS[n] N2HET Pin Disable Bits

0 Logic low: No affect on the output buffer enable of the pin (is controlled by the value of the

HETDIR[n] bit).

1 Logic high: Output buffer of the pin is enabled if pin nDIS = 1, HET_PIN_ENA = 1, and HETDIR =

1; or disabled if nDIS = 0, HETDIR = 0, or HET_PIN_ENA = 0.

Default Chapter2
