Programmable Built-In Self-Test (PBIST) Module
Chapter 9
SPNU563A–March 2018
Programmable Built-In Self-Test (PBIST) Module
This chapter describes the programmable built-in self-test (PBIST) controller module used for testing the
on-chip memories.
Topic ........................................................................................................................... Page
9.1 Overview ......................................................................................................... 406
9.2 RAM Grouping and Algorithm ............................................................................ 407
9.3 PBIST Flow...................................................................................................... 408
9.4 Memory Test Algorithms on the On-chip ROM .................................................... 411
9.5 PBIST Control Registers ................................................................................... 412
9.6 PBIST Configuration Example............................................................................ 426
