IOMM Registers

329

SPNU563A–March 2018

Submit Documentation Feedback

I/O Multiplexing and Control Module (IOMM)

6.7.2 BOOT_REG: Boot Mode Register

Figure 6-11. BOOT_REG: Boot Mode Register (Offset = 20h)

31 16

Reserved

R-0

15 1 0

Reserved ENDIAN

R-0 R-D

LEGEND: R = Read only; D = Value read is determined by external configuration; -n = value after reset

Table 6-14. Boot Mode Register Field Descriptions

Bit Field Value Description

31-1 Reserved 0 Reads return 0, writes have no effect.

0 ENDIAN Device endianness.

0 Device is configured in little-endian mode.

1 Device is configured in big-endian mode.
