High-End Timer Transfer Unit (HTU) Module
Table 24-19. Active Control Packet and Error Register (HTU ACPE) Field Descriptions (continued)
Bit Field Value Description
28-24 ERRETC Error Element Transfer Count
If one of the following conditions happens the current element transfer counter of the control packet
(specified by ERRCPN) is captured to ERRETC. Please see Section 24.2.3.
• Request Lost Error of control packet specified by ERRCPN. This is independent of the CORL bit.
• Parity Error of control packet specified by ERRCPN. This requires the parity check to be enabled,
but is independent of the COPE bit.
• Bus Error of control packet specified by ERRCPN.
• Memory Protection Error of control packet specified by ERRCPN. This requires the memory
protection to be enabled.
• Writing a 1 to a BUSY bit, which belongs to the control packet specified by ERRCPN, if that bit is
1. There is no effect, if the BUSY bit is 0.
ERRETC is frozen from being updated until the upper 16-bit word of the ACPE register or the
complete 32-bit register is read by the CPU. After this read, the HTU will update ERRETC if one of
the above conditions is fulfilled again. During debugging, ERRETC stays frozen even when reading
the upper 16-bit word or the 32-bit register.
23-20 Reserved 0 Reads return 0. Writes have no effect.
19-16 ERRCPN Error Control Packet Number
If one of the conditions listed at ERRETC happens the number of the control packet, which caused
the condition, is captured to ERRCPN.
Control Packet ERRCPN Value
CP A of DCP x 2 x
CP B of DCP x 2 x+1
With x = 0,1,...or 7
ERRCPN is frozen from being updated until the upper 16-bit word of the ACPE register or the
complete 32-bit register is read by the CPU. After this read, the HTU will update ERRCPN if one of
the above conditions is fulfilled again. During debugging, ERRCPN stays frozen even when reading
the upper 16-bit word or the 32-bit register. If one of the conditions is fulfilled, ERRETC and
ERRCPN are updated simultaneously.
15 TIPF Transfer in Progress Flag
0 No transfers are in progress.
1 A transfer is currently active. This bit is the result of a logical OR function of all BUSYxx flags of the
4 BUSYx registers.
14 BUSBUSY Bus is Busy
0 Bus between N2HET and HTU is not busy.
1 When BUSBUSY is 1, the bus is busy with a transfer. It is different from TIPF above because
BUSBUSY will go low after VBUSHOLD is set to 1 and no transfers are pending between the HTU
and the main memory. TIPF will remain 1, if a transfer is still pending and VBUSPHOLD is 1.
13 Reserved 0 Reads return 0. Writes have no effect.
12-8 CETCOUNT Current Element Transfer Count
CETCOUNT shows the current element transfer counter for the frame that is currently processed. If
the HTU does not currently transfer any frame, CETCOUNT is 0.
CETCOUNT is updated after the write part of a transfer. There is a period of up to 7 cycles between
the time the CETCOUNT is 0 and the HTU is finished updating the current DCP (and the CPENA
registers, if the required conditions are fulfilled).
7-4 Reserved 0 Reads return 0. Writes have no effect.
3-0 NACP Number of Active Control Packet
Indicates which CP currently processes a frame.
Active or Recent DCP NACP Value
CP A of DCP x 2 x
CP B of DCP x 2 x+1
With x = 0,1,...or 7
NACP is updated at the time the frame starts on the according CP, and it is updated with a new
value when a frame starts on a different CP. Note, that there can be a delay between the request
and the start of the frame.
