Multi-Buffered Serial Peripheral Interface Module (MibSPI) with Parallel Pin
Option (MibSPIP)
Table 28-43. TG Control Registers (TGxCTRL) Field Descriptions (continued)
Bit Field Value Description
19-16 TRIGSRCx Trigger source. After reset, the trigger sources of all TGs are disabled.
0 Disabled
1h EXT0 External trigger source 0. The actual source varies per device (for example, HET I/O
channel, event pin).
2h EXT1 External trigger source 1. The actual source varies per device (for example, HET I/O
channel, event pin).
3h EXT2 External trigger source 2. The actual source varies per device (for example, HET I/O
channel, event pin).
4h EXT3 External trigger source 3. The actual source varies per device (for example, HET I/O
channel, event pin).
5h EXT4 External trigger source 4. The actual source varies per device (for example, HET I/O
channel, event pin).
6h EXT5 External trigger source 5. The actual source varies per device (for example, HET I/O
channel, event pin).
7h EXT6 External trigger source 6. The actual source varies per device (for example, HET I/O
channel, event pin).
8h EXT7 External trigger source 7. The actual source varies per device (for example, HET I/O
channel, event pin).
9h EXT8 External trigger source 8. The actual source varies per device (for example, HET I/O
channel, event pin).
Ah EXT9 External trigger source 9. The actual source varies per device (for example, HET I/O
channel, event pin).
Bh EXT10 External trigger source 10. The actual source varies per device (for example, HET I/O
channel, event pin).
Ch EXT11 External trigger source 11. The actual source varies per device (for example, HET I/O
channel, event pin).
Dh EXT12 External trigger source 12. The actual source varies per device (for example, HET I/O
channel, event pin).
Eh EXT13 External trigger source 13. The actual source varies per device (for example, HET I/O
channel, event pin).
Fh TICK Internal periodic event trigger. The tick counter can initiate periodic group transfers.
15-8 PSTARTx 0-FFh TG start address. PSTARTx stores the start address of the corresponding TG. The corresponding
end address is inherently defined by the subsequent TG start address minus 1 (PENDx[TGx] =
PSTARTx[TGx+1]-1). PSTARTx is copied into PCURRENTx when:
• The TG is enabled.
• The end of the TG is reached during a transfer.
• A trigger event occurs while PRST is set to 1.
Note: For MibSPI1 that supports 256 buffers (values from 0-FFh), bit 15 is used. For
MibSPI2-5 that support 128 buffers (values from 0-7Fh), bit 15 is reserved.
7-0 PCURRENTx 0-FFh Pointer to current buffer. PCURRENT is read-only. PCURRENTx stores the address of the buffer
that corresponds to this TG. If the TG switches from active transfer mode to suspend to wait,
PCURRENTx contains the address of the currently suspended word. After the TG resumes from
suspend to wait mode, the next buffer will be transferred; that is, no buffer data is transferred
because of suspend to wait mode.
Note: For MibSPI1 that supports 256 buffers (values from 0-FFh), bit 7 is used. For MibSPI2-
5 that support 128 buffers (values from 0-7Fh), bit 7 is reserved.
NOTE: Register bits vary by device
TG0 has the highest priority and TG15 has the lowest priority. Under the following conditions
a lower priority TG cannot be interrupted by a higher priority TG.
1. When there is a CSHOLD or LOCK buffer, until the completion of the next buffer
transfer which is a non-CSHOLD or non-LOCK buffer.
2. An entire sequence of words transferred for a NOBRK DMA buffer.
3. Once the last word in a TG is pre-fetched.
