NMPU Registers

www.ti.com

480

SPNU563A–March 2018

Submit Documentation Feedback

System Memory Protection Unit (NMPU)

Table 11-14. MPU Region Size and Enable Register (MPUREGSENA) Field Descriptions (continued)

Bit Field Value Description

5-1 REG_SIZE MPU Region size. This field determines the size of an MPU region.

Read: Returns current value of REG_SIZE.

Write in Privilege: Defines the size of an MPU region.

0-3h Reserved

4h 32 bytes

5h 64 bytes

6h 128 bytes

7h 256 bytes

8h 512 bytes

9h 1 KB

Ah 2 KB

Bh 4 KB

Ch 8 KB

Dh 16 KB

Eh 32 KB

Fh 64 KB

10h 128 KB

11h 256 KB

12h 512 KB

13h 1 MB

14h 2 MB

15h 4 MB

16h 8 MB

17h 16 MB

18h 32 MB

19h 64 MB

1Ah 128 MB

1Bh 256 MB

1Ch 512 MB

1Dh 1 GB

1Eh 2 GB

1Fh 4 GB

0 REGENA MPU Region Enable. This is the register bit for enabling an MPU region.

Read:

0 MPU region is disabled.

1 MPU region is enabled.

Write in Privilege:

0 Disable MPU region.

1 Enable MPU region.
