TC1796
Peripheral Units (Vol. 2 of 2)
Micro Second Channel (MSC)
User’s Manual 21-50 V2.0, 2007-07
MSC, V2.0
ECIP [5:4] rw Command Frame Interrupt Node Pointer
ECIP selects the service request output line SRn
(n = 3-0) for the command frame interrupt.
00
B
Service request output SR0 selected
01
B
Service request output SR1 selected
10
B
Service request output SR2 selected
11
B
Service request output SR3 selected
ECIE 7rwCommand Frame Interrupt Enable
This bit enables the command frame interrupt.
0
B
Interrupt generation disabled.
1
B
Interrupt generation enabled.
TFIP [9:8] rw Time Frame Interrupt Pointer
TFIP selects the service request output line SRn
(n = 3-0) for the time frame interrupt.
00
B
Service request output SR0 selected
01
B
Service request output SR1 selected
10
B
Service request output SR2 selected
11
B
Service request output SR3 selected
TFIE 11 rw Time Frame Interrupt Enable
This bit enables the time frame interrupt.
0
B
Interrupt generation disabled.
1
B
Interrupt generation enabled.
RDIP [13:12] rw Receive Data Interrupt Pointer
RDIP selects the service request output line SRn
(n = 3-0) for the receive data interrupt.
00
B
Service request output SR0 selected
01
B
Service request output SR1 selected
10
B
Service request output SR2 selected
11
B
Service request output SR3 selected
Field Bits Type Description
