Infineon Technologies TC1796 User Manual

TC1796
Peripheral Units (Vol. 2 of 2)
Controller Area Network (MultiCAN) Controller
User’s Manual 22-194 V2.0, 2007-07
MultiCAN, V2.0
STSRH
Scheduler Timing Status Register High
(2F4
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TCEMSGNR RCEMSGNR
rh rh
1514131211109876543210
TMETMV
rh
Field Bits Type Description
TMETMV [15:0] rh Time Mark Value from TME
This bit field indicates the compare value for the next
time mark defined by an TME. This value is valid only
if SISR.ICF = 1 and SISR.TMEV = 1.
RCEMSGNR [23:16] rh Receive Control Entry Message Number
This bit field indicates the collected RCEMSGNR
information from an RCE. This value is taken into
account only if SISR.ICF = 1 and SISR.RCEV = 1.
TCEMSGNR [31:24] rh Transmit Control Entry Message Number
This bit field indicates the collected TCEMSGNR
information from an TCE. This value is taken into
account only if SISR.ICF = 1 and SISR.TCEV = 1.
