TC1796
Peripheral Units (Vol. 2 of 2)
Controller Area Network (MultiCAN) Controller
User’s Manual 22-196 V2.0, 2007-07
MultiCAN, V2.0
CHEN 8rhCheck Enable
This bit field indicates the collected CHEN
information from an RCE.
CHEN is taken into account only if EC indicates an
RCE.
TREN 9rhTransmit Enable
This bit field indicates the collected TREN
information from an TCE.
ALTMSG [11:10] rh Alternative Message
This bit field indicates the collected ALTMSG
information from an TCE.
ARBM [13:12] rh Arbitration Mode
This bit field indicates the collected ARBM
information from an TME or an ARBE.
GM 14 rh Gap Mode
This bit field indicates the collected GM information
from an RME or an BCE only valid if RME or a BCE
has been found).
ICF 15 rh Instruction Collection Finished
This bit field indicates that the instruction collection is
finished for a time window. It is automatically cleared
when a time mark is reached. It is set when the
instruction collection is terminated.
0
B
The instruction collection is not yet terminated.
All other values in registers SISR, STSR0 and
STSR4 are invalid.
1
B
The instruction collection is terminated. All
other values in registers SISR, STSR0 and
STSR4 are valid.
Field Bits Type Description
