TC1796
Peripheral Units (Vol. 2 of 2)
Controller Area Network (MultiCAN) Controller
User’s Manual 22-197 V2.0, 2007-07
MultiCAN, V2.0
RCEV 16 rh Receive Control Entry Valid
This bit indicates that a valid receive control
information has been found during the instruction
collection for this time window. It is automatically
cleared when a time mark is reached.
0
B
The bit fields CHEN and RCEMSGNR are
invalid. They are not taken into account for the
next time window.
1
B
The bit fields CHEN and RCEMSGNR are
valid. They are taken into account for the next
time window.
TCEV 17 rh Transmit Control Entry Valid
This bit indicates that valid transmit control
information has been found during the instruction
collection for this time window. It is automatically
cleared when a time mark is reached.
0
B
The bit fields TREN, ALTMSG and
TCEMSGNR are invalid. They are not taken
into account for the next time window.
1
B
The bit fields TREN, ALTMSG and
TCEMSGNR are valid. They are taken into
account for the next time window.
ICEV 18 rh Interrupt Control Entry Valid
This bit indicates that a valid interrupt control entry
has been found during the instruction collection for
this time window. It is automatically cleared when a
time mark is reached.
0
B
No valid ICE has been found
1
B
A valid ICE has been found
ARBV 19 rh Arbitration Entry Valid
This bit indicates that a valid arbitration entry has
been found during the instruction collection for this
time window. It is automatically cleared when a time
mark is reached.
0
B
No valid ARBE has been found
1
B
A valid ARBE has been found
