TC1796

System Units (Vol. 1 of 2)

System Control Unit

User’s Manual 5-25 V2.0, 2007-07

SCU, V2.0

The Pattern Detection Result Register monitors the combinatorial output status of the

pattern detection units.

PDRR

Pattern Detection Result Register (F0000090

) Reset Value: 0000 000F

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

1514131211109876543210

PDR

r rhrhrhrh

Field Bits Type Description

PDRy

(y = 0-3)

yrhPattern Detection Result of Channel y

This bit monitors the output status of the pattern

detection for the output channel y.

0 [31:4] r Reserved

Read as 0; should be written with 0.
