TC1796

System Units (Vol. 1 of 2)

System Control Unit

User’s Manual 5-46 V2.0, 2007-07

SCU, V2.0

SCU_TCLR0

SCU Temperature Compensation 0 Level Register

(F0000058

) Reset Value: 02FF FFFF

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

THCOUNT THMAX0

rh rw

1514131211109876543210

THMED0 THMIN0

rw rw

Field Bits Type Description

THMIN0 [7:0] rw Minimum Threshold for Temp. Compensation 0

Driver level = Low or Min

THMED0 [15:8] rw Medium Threshold for Temp. Compensation 0

Driver level = High or Low

THMAX0 [23:16] rw Maximum Threshold for Temp. Compensation 0

Driver level = Max or High

THCOUNT [31:24] rh Threshold Counter

Returns the actual count value of the counter that

counts the f

POSC

clock pulses. THCOUNT is only

updated when temperature compensation is enabled

(TCE0 or TCE1 or both set).
