TC1796
System Units (Vol. 1 of 2)
On-Chip System Buses and Bus Bridges
User’s Manual 6-12 V2.0, 2007-07
Buses, V2.0
DBCU_LEADDR
DBCU LMB Error Address Register (24
H
) Reset Value: XXXX XXXX
H
PBCU_LEADDR
PBCU LMB Error Address Register (24
H
) Reset Value: XXXX XXXX
H
31 0
LEADDR
rh
Field Bits Type Description
LEADDR [31:0] rh LMB Address
This bit field holds the LMB address that has been
captured at an LMB bus error.
LEADDR only contains valid read data when bit LEC
in the corresponding register LEATT is set.
DBCU_LEDATL
DBCU LMB Error Data Low Register (28
H
) Reset Value: XXXX XXXX
H
PBCU_LEDATL
PLMB LMB Error Data Low Register (28
H
) Reset Value: XXXX XXXX
H
31 0
LEDAT[31:0]
rh
Field Bits Type Description
LEDAT[31:0] [31:0] rh LMB Bus Address Bits [31:0]
This bit field holds the lower 32-bit part of the 64-bit
LMB data that has been captured at an LMB bus
error.
LEDAT[31:0] only contains valid read data when bit
LEC in the corresponding register LEATT is set.
