Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Direct Memory Access Controller
User’s Manual 12-95 V2.0, 2007-07
DMA, V2.0
Table 12-10 DMA Request Assignment for DMA Sub-Block 1
DMA
Channel
DMA Request Source DMA Request Unit Selected by
10 CH07_OUT DMA channel 07 CHCR10.PRSEL = 000
B
SCU_REQ0 Ext. Request Unit
1)
CHCR10.PRSEL = 001
B
SR0 FADC CHCR10.PRSEL = 010
B
SR6 ADC0 CHCR10.PRSEL = 011
B
SR6 ADC1 CHCR10.PRSEL = 100
B
SR4 MLI0 CHCR10.PRSEL = 101
B
SR4 MLI1 CHCR10.PRSEL = 110
B
not connected (0) CHCR10.PRSEL = 111
B
11 CH10_OUT DMA channel 10 CHCR11.PRSEL = 000
B
SCU_REQ1 Ext. Request Unit
1)
CHCR11.PRSEL = 001
B
SR1 FADC CHCR11.PRSEL = 010
B
SR7 ADC0 CHCR11.PRSEL = 011
B
SR7 ADC1 CHCR11.PRSEL = 100
B
SR5 MLI0 CHCR11.PRSEL = 101
B
SR5 MLI1 CHCR11.PRSEL = 110
B
not connected (0) CHCR11.PRSEL = 111
B
12 CH11_OUT DMA channel 11 CHCR12.PRSEL = 000
B
SCU_REQ2 Ext. Request Unit
1)
CHCR12.PRSEL = 001
B
SR2 FADC CHCR12.PRSEL = 010
B
SR4 ADC0 CHCR12.PRSEL = 011
B
SR4 ADC1 CHCR12.PRSEL = 100
B
SR6 MLI0 CHCR12.PRSEL = 101
B
SR6 MLI1 CHCR12.PRSEL = 110
B
not connected (0) CHCR12.PRSEL = 111
B
