www.ti.com
Instruction Set
1061
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer (N2HET) Module
Table 23-74. FLAGS Generated by Instruction
Abbreviation Flag Name Set/Reset by Used by
C Carry Flag ADC, ADD, AND, OR, RCNT, SBB, SUB, XOR ADC, BR, SBB
N Negative Flag ADC, ADD, AND, OR, SBB, SUB, XOR BR
V Overflow Flag ADC, ADD, AND, OR, SBB, SUB, XOR BR
Z Zero flag
ACNT, ADC, ADD, AND, APCNT, CNT, OR, PCNT,
SBB, SCNT, SHFT, SUB, XOR
ACMP, ACNT, BR, ECMP,
MCMP, MOV32, RCNT,
SCMP, SHFT
X
Angle Compare Match
Flag
ACMP SCMP
SWF 0-1 Step Width flags SCNT ACNT
NAF New Angle Flag ACNT NAF_global
NAF_global New Angle Flag (global) HWAG or NAF
ACMP, BR, CNT, ECMP,
ECNT
ACF Acceleration Flag ACNT ,ACNT, SCNT
DCF Deceleration Flag ACNT ,ACNT, SCNT
GPF Gap Flag ACNT ACNT, APCNT
The instructions capable of generating software interrupts are listed in Table 23-75.
Table 23-75. Interrupt Capable Instructions
Interrupt Capable Instructions Non Interrupt Capable Instructions
ACMP ADC
ACNT ADCNST
APCNT ADD
BR ADM32
CNT AND
DJZ DADM32
ECMP MOV32
ECNT MOV64
MCMP OR
PCNT RADM64
PWCNT RCNT
SCMP SBB
SHFT SCNT
WCAP SUB
WCAPE XOR
