Texas Instruments TMS570LC4357 User Manual

Instruction Set www.ti.com
1094
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer (N2HET) Module
23.6.3.11 ECMP (Equality Compare)
Syntax ECMP {
[brk={OFF | ON}]
[next={label | 9-bit unsigned integer}]
[reqnum={3-bit unsigned integer}
[request={NOREQ | GENREQ | QUIET}]
[hr_lr={HIGH | LOW}]
[angle_comp={OFF | ON}]
[control={OFF | ON}]
[en_pin_action={OFF | ON}]
[cond_addr={label | 9-bit unsigned integer}]
pin={pin number}
[action={CLEAR | SET | PULSELO | PULSEHI}]
[reg={A | B | R | S| T | NONE}]
[irq={OFF | ON}]
[data={25-bit unsigned integer]
[hr_data={7-bit unsigned integer}]
}
Figure 23-144. ECMP Program Field (P31:P0)
31 26 25 23 22 21 13 12 9 8 7 6 0
0 Request
Number
BRK Next program address 0000 hr_lr Angle
comp.
Reserved
6 3 1 9 4 1 1 7
Figure 23-145. ECMP Control Field (C31:C0)
31 29 28 27 26 25 23 22 21 16
Reserved Request type Control Reserved En. pin
action
Conditional address
3 2 1 3 1 9
15 13 12 8 7 6 5 4 3 2 1 0
Conditional address Pin select Ext
Reg
00 Action Register select Int.
ena
9 5 1 2 2 2 1
Figure 23-146. ECMP Data Field (D31:D0)
31 7 6 0
Data HR Data
25 7
