High-End Timer (N2HET) Module

Table 23-88. MOV64 Control Field Descriptions (continued)

action Maintains the control field for the remote instruction.

irq Maintains the control field for the remote instruction.

data Specifies the 25-bit initial count value for the data field. If omitted, the field defaults to 0.

hr_data (Optional) HR delay. The default value for an unspecified bit is 0.

Table 23-89. Comparison Type Encoding Format

comp_mode C[6] C[5] MCMP Order

ECMP 0 0

SCMP 0 1

MCMP1 1 0 REG_GE_DATA

MCMP2 1 1 DATA_GE_REG

Execution

Remote Data Field = Immediate Data Field;

Remote Control Field = Immediate control Field;

Jump to Next Program Address;
