Immediate CF + DF
Remote CF + DF
HR
HR
www.ti.com
Instruction Set
1107
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer (N2HET) Module
Figure 23-160. MOV64 Program Field (P31:P0)
31 26 25 23 22 21 13 12 9 8 0
0 Reserved BRK Next program address 0001 Remote Address
6 3 1 9 4 9
Figure 23-161. MOV64 Control Field (C31:C0)
31 29 28 27 26 25 23 22 21 16
Reserved Request type Control Reserved En. pin
action
Conditional address
3 2 1 3 1 9
15 13 12 8 7 6 5 4 3 2 1 0
Conditional address Pin select Ext
Reg
Comp. mode Action Register select Int.
ena
9 5 1 2 2 2 1
Figure 23-162. MOV64 Data Field (D31:D0)
31 7 6 0
Data HR Data
25 7
Cycles One
Register modified None
Description This instruction modifies the data field and the control field at the remote
address.
MOV64 has two distinct syntaxes. In the first syntax, bit values may be set by
assigning a value to each of the control fields. This syntax is convenient for
modifying control fields that are arranged similarly to the format of the MOV64
control field. A second syntax, in which the entire 29-bit control field is
specified by the cntl_val field, is convenient when the remote control field is
dissimilar to the MOV64 control field. Either syntax may be used, but you must
use one or the either but not a combination of syntaxes. See Figure 23-163.
Figure 23-163. MOV64 Move Operation
Table 23-88. MOV64 Control Field Descriptions
request Maintains the control field for the remote instruction.
control Maintains the control field for the remote instruction.
en_pin_action Maintains the control field for the remote instruction.
cond_addr Maintains the control field for the remote instruction.
pin Maintains the control field for the remote instruction.
register, ext reg Maintains the control field for the remote instruction.
comp_mode Selects the comparison mode type to be used by the remote instruction.
