High-End Timer (N2HET) Module
smode Shift mode
Table 23-94. SHIFT MODE Encoding Format
smode P3 P2 P1 P0 Operation
OR0 0 0 0 0 Shift Out / Right LSB 1st on HETx / 0 into MSB
OL0 0 0 0 1 Shift Out / Left MSB 1st on HETx / 0 into LSB
OR1 0 0 1 0 Shift Out / Right LSB 1st on HETx / 1 into MSB
OL1 0 0 1 1 Shift Out / Left MSB 1st on HETx / 1 into LSB
ORZ 0 1 0 0 Shift Out / Right LSB 1st on HETx / Z into MSB
OLZ 0 1 0 1 Shift Out / Left MSB 1st on HETx / Z into LSB
IRM 1 0 0 0 Shift In / Right HETx into MSB
ILL 1 0 0 1 Shift In / Left HETx into LSB
IRZ 1 0 1 0 Shift In / Right HETx in MSB / LSB into Z
ILZ 1 0 1 1 Shift In / Left HETx in LSB / MSB into Z
cond Specifies the shift condition.
Table 23-95. SHIFT Condition Encoding
C6 C5 Shift Condition
0 X Always
1 0 Rising edge of HET[0]
1 1 Falling edge of HET[0]
irq ON generates an interrupt if the Z flag is set. A value of OFF does not
generate an interrupt.
Default: OFF.
data Specifies the 25-bit value for the data field.
