Table 26-22. Transfer Status Current Buffer (TSCB) Field Descriptions (continued)
Bit Field Value Description
8 IDLE Detects Transfer State Machine State IDLE.
Will be set if the transfer unit state machine is in IDLE state and ready to start the next transfer,
but nothing is requested.
0 IDLE state is not reached since last clear.
1 IDLE state is reached.
7 Reserved 0 Reads return 0. Writes have no effect.
6-0 BN 0-7Fh Buffer number.
7-bit value of buffer number, which is currently in transfer. If state machine enters IDLE mode the
last transferred buffer number is shown.
26.3.1.5 Last Transferred Buffer to Communication Controller (LTBCC)
Shows the number of the last completely transferred message buffer from system memory to the
communication controller.
Figure 26-37. Last Transferred Buffer to Communication Controller (LTBCC) [offset_TU = 1Ch]
31 7 6 0
Reserved BN
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 26-23. Last Transferred Buffer to Communication Controller (LTBCC) Field Descriptions
Bit Field Value Description
31-7 Reserved. 0 Reads return 0. Writes have no effect.
6-0 BN 0-7Fh Buffer number.
7-bit value of last completely transferred message buffer from system memory to the communication
controller.
26.3.1.6 Last Transferred Buffer to System Memory (LTBSM)
Shows the number of the last completely transferred message buffer from communication controller to the
system memory.
Figure 26-38. Last Transferred Buffer to System Memory (LTBSM) [offset_TU = 20h]
31 7 6 0
Reserved BN
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 26-24. Last Transferred Buffer to System Memory (LTBSM) Field Descriptions
Bit Field Value Description
31-7 Reserved 0 Reads return 0. Writes have no effect.
6-0 BN 0-7Fh Buffer number.
7-bit value of last completely transferred message buffer from system memory to the
communication controller to the system memory.
