www.ti.com
FlexRay Module Registers
1305
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
Figure 26-70. Trigger Transfer to Communication Controller Set 3 (TTCCS3) [offset_TU = B0h]
31 16
TTCCS3[95-80]
R/WS-0
15 0
TTCCS3[79-64]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-50. Trigger Transfer to Communication Controller Set 3 (TTCCS3) Field Descriptions
Bit Field Value Description
31-0 TTCCS3[n] Trigger Transfer to Communication Controller Set 3. The register bits 0 to 31 correspond to
message buffers 64 to 95. Each bit of the register controls the message buffer transfer to the
communication controller in the following manner.
0 No transfer request.
1 Transfer based on address defined in TBA.
Figure 26-71. Trigger Transfer to Communication Controller Reset 3 (TTCCR3) [offset_TU = B4h]
31 16
TTCCR3
R/WC-0
15 0
TTCCR3
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-51. Trigger Transfer to Communication Controller Reset 3 (TTCCR3) Field Descriptions
Bit Field Description
31-0 TTCCR3 Trigger Transfer to Communication Controller Reset 3. The TTCCR3 register shows the identical values to
TTCCS3 if read.
