EMAC/MDIO Module
Figure 32-11. Receive Buffer Descriptor Format
Word 0
31 0
Next Descriptor Pointer
Word 1
31 0
Buffer Pointer
Word 2
31 16 15 0
Buffer Offset Buffer Length
Word 3
31 30 29 28 27 26 25 24
SOP EOP OWNER EOQ TDOWNCMPLT PASSCRC JABBER OVERSIZE
23 22 21 20 19 18 17 16
FRAGMENT UNDERSIZED CONTROL OVERRUN CODEERROR ALIGNERROR CRCERROR NOMATCH
15 0
Packet Length
Example 32-2. Receive Buffer Descriptor in C Structure Format
/*
// EMAC Descriptor
//
// The following is the format of a single buffer descriptor
// on the EMAC.
*/
typedef struct _EMAC_Desc {
struct _EMAC_Desc *pNext; /* Pointer to next descriptor in chain */
Uint8 *pBuffer; /* Pointer to data buffer */
Uint32 BufOffLen; /* Buffer Offset(MSW) and Length(LSW) */
Uint32 PktFlgLen; /* Packet Flags(MSW) and Length(LSW) */
} EMAC_Desc;
/* Packet Flags */
#define EMAC_DSC_FLAG_SOP 0x80000000u
#define EMAC_DSC_FLAG_EOP 0x40000000u
#define EMAC_DSC_FLAG_OWNER 0x20000000u
#define EMAC_DSC_FLAG_EOQ 0x10000000u
#define EMAC_DSC_FLAG_TDOWNCMPLT 0x08000000u
#define EMAC_DSC_FLAG_PASSCRC 0x04000000u
#define EMAC_DSC_FLAG_JABBER 0x02000000u
#define EMAC_DSC_FLAG_OVERSIZE 0x01000000u
#define EMAC_DSC_FLAG_FRAGMENT 0x00800000u
