EPWMxSYNCI

TBCTR[15:0]

CTR_dir

CTR = zero

CNT_max

CTR = PRD

0xFFFF

TBPHS

(value)

TBPRD

(value)

ePWM Submodules

www.ti.com

2008

SPNU563A–March 2018

Submit Documentation Feedback

Copyright © 2018, Texas Instruments Incorporated

Enhanced Pulse Width Modulator (ePWM) Module

Figure 35-7. Time-Base Up-Count Mode Waveforms
