www.ti.com
ePWM Registers
2107
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Enhanced Pulse Width Modulator (ePWM) Module
35.4.8.9 Digital Compare Counter Capture Register (DCCAP)
Figure 35-99. Digital Compare Counter Capture Register (DCCAP) [offset = 70h]
15 0
DCCAP
R-0
LEGEND: R = Read only; -n = value after reset
Table 35-59. Digital Compare Counter Capture Register (DCCAP) Field Descriptions
Bit Field Description
15-0 DCCAP Digital Compare Time-Base Counter Capture.
To enable time-base counter capture, set the DCCAPCLT[CAPE] bit to 1.
If enabled, reflects the value of the time-base counter (TBCTR) on the low-to-high edge transition of a
filtered (DCEVTFLT) event. Further capture events are ignored until the next period or zero as selected by
the DCFCTL[PULSESEL] bit.
Shadowing of DCCAP is enabled and disabled by the DCCAPCTL[SHDWMODE] bit. By default this
register is shadowed.
• If DCCAPCTL[SHDWMODE] = 0, then the shadow is enabled. In this mode, the active register is copied
to the shadow register on the TBCTR = TBPRD or TBCTR = zero as defined by the
DCFCTL[PULSESEL] bit. CPU reads of this register will return the shadow register value.
• If DCCAPCTL[SHDWMODE] = 1, then the shadow register is disabled. In this mode, CPU reads will
return the active register value.
The active and shadow registers share the same memory-map address.
35.4.8.10 Digital Compare Filter Window Counter Register (DCFWINDOWCNT)
Figure 35-100. Digital Compare Filter Window Counter Register (DCFWINDOWCNT) [offset = 72h]
15 8
Reserved
R-0
7 0
WINDOWCNT
R-0
LEGEND: R = Read only; -n = value after reset
Table 35-60. Digital Compare Filter Window Counter Register (DCFWINDOWCNT) Field
Descriptions
Bit Field Value Description
15-8 Reserved 0 Any writes to these bit(s) must always have a value of 0.
7-0 WINDOWCNT 0-FFh Blanking Window Counter.
These 8 bits are read-only and indicate the current value of the window counter. The counter
counts down to zero and then stops until it is re-loaded when the offset counter reaches zero again.
