RTP Control Registers

www.ti.com

2184

SPNU563A–March 2018

Submit Documentation Feedback

RAM Trace Port (RTP)

Table 37-24. RTP Pin Control 6 Register (RTPPC6) Field Descriptions (continued)

Bit Field Value Description

15-0 DATAPDR[n] RTPDATA[15:0] Open drain enable. These bits enable open drain functionality on the pins if they

are configured as a GIO output (RTPPC0[15:0] = 0; RTPPC1[15:0] = 1). If the pins are configured

as a functional pins (RTPPC0[15:0] = 1), the open drain functionality is disabled. Each bit [n]

represents a single pin.

Read:

0 Pin behaves as normal push/pull pin.

1 Pin operates in open drain mode.

Write:

0 Configures the pin as push/pull.

1 Configures the pin as open drain.
