Texas Instruments TMS570LC4357 User Manual

RTP Control Registers www.ti.com
2186
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
RAM Trace Port (RTP)
37.3.17 RTP Pin Control 8 Register (RTPPC8)
This register configures the internal pullup or pulldown on the input pin. A secondary function exists when
the pull configuration is disabled and a pulldown is selected. This will disable the input buffer. Figure 37-25
and Table 37-26 describe this register.
NOTE: If the pullup/down is disabled in the RTPPC7 register and configured as pulldown in
RTPPC8, then the input buffer is disabled.
Figure 37-25. RTP Pin Control 8 Register (RTPPC8) (offset = 54h)
31 19 18 17 16
Reserved ENAPSEL CLKPSEL SYNCPSEL
R-0 R/W-1 R/W-1 R/W-1
15 0
DATAPSEL[15:0]
R/W-1
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 37-26. RTP Pin Control 8 Register (RTPPC8) Field Descriptions
Bit Field Value Description
31-19 Reserved 0 Reads return 0. Writes have no effect.
18 ENAPSEL RTPENA Pull select. This bit configures pullup or pulldown functionality if RTPPC7[18] = 0.
Read:
0 Pulldown functionality is enabled.
1 Pullup functionality is enabled.
Write:
0 Enables pulldown functionality.
1 Enables pullup functionality.
17 CLKPSEL RTPCLK Pull select. This bit configures pullup or pulldown functionality if RTPPC7[17] = 0.
Read:
0 Pulldown functionality is enabled.
1 Pullup functionality is enabled.
Write:
0 Enables pulldown functionality.
1 Enables pullup functionality.
16 SYNCPSEL RTPSYNC Pull select. This bit configures pullup or pulldown functionality if RTPPC7[16] = 0.
Read:
0 Pulldown functionality is enabled.
1 Pullup functionality is enabled.
Write:
0 Enables pulldown functionality.
1 Enables pullup functionality.
15-0 DATAPSEL[n] RTPDATA[15:0] Pull select. These bits configure pullup or pulldown functionality if RTPPC7[15:0] =
0. Each bit [n] represents a single pin.
Read:
0 Pulldown functionality is enabled.
1 Pullup functionality is enabled.
Write:
0 Enables pulldown functionality.
1 Enables pullup functionality.
