System and Peripheral Control Registers

www.ti.com

238

SPNU563A–March 2018

Submit Documentation Feedback

Architecture

2.5.3.28 MasterID Enable Register (MSTIDENA)

Figure 2-99. MasterID Enable Register (MSTIDENA) (offset = 204h)

31 16

Reserved

R-0

15 4 3 0

Reserved MSTID_CHK_ENA

R-0 R/WP-5h

LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after reset

Table 2-113. MasterID Enable Register (MSTIDENA) Field Descriptions

Bit Field Value Description

31-4 Reserved 0 Reads return 0. Writes have no effect.

3-0 MSTID_CHK_ENA MasterID Check Enable. This is a 4-bit key for enabling Master-ID check. This key must be

programmed with 1010 to enable Master-ID Check functionality.

Ah Read: The master-ID check is enabled.

Write: Enable master-ID check.

Others Read: The master-ID check is disabled.

Write: Disable master-ID check.
