2.5.3.37 Privileged Peripheral Extended Frame 0 MasterID Protection Register_H (PPSE0MSTID_H)
Figure 2-108. Privileged Peripheral Extended Frame 0 MasterID Protection Register_H
(PPSE0MSTID_H) (offset = 444h)
31 16
PPSE0_QUAD3_MSTID
R/WP-FFFFh
15 0
PPSE0_QUAD2_MSTID
R/WP-FFFFh
LEGEND: R/W = Read/Write; WP = Write in privileged mode only; -n = value after reset
Table 2-122. Privileged Peripheral Extended Frame 0 MasterID Protection Register_H
(PPSE0MSTID_H) Field Descriptions
Bit Field Value Description
31-16 PPSE0_QUAD3_MSTID MasterID filtering for Quadrant 3 of PPSE[0].
0 Read: The corresponding master-ID is not permitted to access the peripheral.
Write: Disable the permission of the corresponding master to access the peripheral.
1 Read: The corresponding master-ID is permitted to access the peripheral.
Write: Enable the permission of the corresponding master to access the peripheral.
15-0 PPSE0_QUAD2_MSTID MasterID filtering for Quadrant 2 of PPSE[0].
0 Read: The corresponding master-ID is not permitted to access the peripheral.
Write: Disable the permission of the corresponding master to access the peripheral.
1 Read: The corresponding master-ID is permitted to access the peripheral.
Write: Enable the permission of the corresponding master to access the peripheral.
