Direct Memory Access Controller (DMA) Module
20.3.1.84 DMA Single-Bit ECC Control Register (DMASECCCTRL)
Figure 20-101. DMA Single-Bit ECC Control Register (DMASECCCTRL) [offset = 228h]
31 17 16
Reserved SBERR
R-0 R/W1CP-0
15 12 11 8 7 4 3 0
Reserved SBE_EVT_EN Reserved EDACMODE
R-0 R/WP-5h R-0 R/WP-Ah
LEGEND: R/W = Read/Write; R = Read only; W1CP = Write 1 to clear in privilege mode only; WP = Write in privilege mode only; -n = value
after reset
Table 20-91. DMA Single-Bit ECC Control Register (DMASECCCTRL) Field Description
Bit Field Value Description
31-17 Reserved 0 Reads return 0. Writes have no effect.
16 SBERR Error action.
0 Read: No RAM check error has occurred.
Write: No effect.
1 Read: A single-bit error has occurred and was corrected by the SECDED logic.
Write: Clears the bit.
15-12 Reserved 0 Reads return 0. Writes have no effect.
11-8 SBE_EVT_EN Single-bit error enable.
5h Disable generation of single-bit error to ESM.
Ah Enable generation of single-bit error to ESM.
7-4 Reserved 0 Reads return 0. Writes have no effect.
3-0 EDACMODE 5h Disable correction of SBE detected by the SECDED block.
Ah Enable correction of SBE detected by the SECDED block.
