Registers

Gap Veriﬁcation

Toothed

Wheel

Peripheral

bus

Int

ICLK

Angle increment

HET Resolution

To HET

To CPU

HWAG

Angle Tick

Generation

Noise Filtering

HET Interface

HWAG core

Angle Functions

www.ti.com

996

SPNU563A–March 2018

Submit Documentation Feedback

High-End Timer (N2HET) Module

23.3.2.1.2 Block Diagram

Figure 23-36. Hardware Angle Generator Block Diagram
